Geometric NestingWorks 2025 SP1 is an add-in for SolidWorks, developed by Geometric Americas (HCL), that enables the automated, true-shape nesting of parts and assemblies made from sheet materials—such as metal, plastic, composites, wood, or sheet metal.
Geometric NestingWorks 2025 SP1 Description
It runs directly inside SolidWorks, preserving a seamless workflow from design to manufacturing. It leverages the powerful NESTLib® engine, known for its high-speed, feature-rich clustering and optimization capabilities.
NestingWorks is a powerful plugin for SolidWorks software that allows you to divide various models and parts designed in NestingWorks SOLIDWORKS Download into multiple parts and networks, and design nested layers and complex parts of models, especially metal sheets, in two-dimensional and three-dimensional formats.
NestingWorks for SolidWorks Free Download is fully integrated with the SolidWorks software environment and, in addition, features a comprehensive tool and library that allows users to design or build multiple layers, parts, and networks from a model designed with a variety of materials, including wood, composites, metal, and more.
Features Of Geometric NestingWorks 2025 SP1
- True-shape nesting: Parts are packed based on their actual geometry, not bounding boxes, enabling tighter layouts and less material waste.
- Part-in-part nesting: Smaller parts can nest within the voids of larger ones, maximizing material utilization.
- Variable thickness handling: Automatically nests parts that share the same thickness, streamlining the process of grouping and layout generation.
- Grain direction specification: Especially useful for anisotropic materials—users can define grain or pattern orientation for parts during nesting.
- Full associativity with designs: Nesting layouts auto-update as the underlying designs change in SolidWorks.
- Seamless integration: Operates entirely within the SolidWorks interface, allowing nested results to be output as new assemblies for downstream CAM processes.
