ZWSIM Structural 2026 is a finite-element analysis (FEA) software developed by ZWSOFT — designed to perform structural and thermal simulations in an integrated modeling-and-simulation environment.
ZWSIM Structural 2026 Description
It allows engineers, designers, and analysts to take CAD geometry (or create geometry), mesh it, apply loads/boundary conditions, and simulate real-world mechanical or thermal behavior of structures or components. ZWSim Structural 2026 supports static, dynamic, and heat transfer problems of structures and can calculate displacement, stress, strain, velocity, acceleration, buckling coefficient, natural frequency, temperature distribution, heat flow, etc.
In other words, ZWSim Structural is a structural simulator that integrates modeling and simulation. The finite element method (FEM) simulates the physical behaviors of structures. Solving structural mechanics problems helps engineers in various industries evaluate the rationality of structural design, make faster and better decisions, and reduce research and development time and cost.
Features For ZWSIM Structural 2026
Structural / Mechanical Analysis
-
Linear statics & dynamics: static loads, stress/strain analysis, stiffness, stability, etc.
-
Modal & vibration analysis: modal shapes/frequencies, harmonic response, transient and spectrum response analyses — useful for checking dynamic behavior, natural frequencies, vibration response, stability under dynamic loads.
-
Nonlinear & contact analysis: supports geometric nonlinearity (large displacements/deformations), complex contact interactions (bonded, frictional, rough, adhesive), and nonlinear materials — helpful when modeling real-life behavior under large loads/deformations.
-
Fatigue & lifespan analysis: ability to simulate cyclic loading, variable amplitude, harmonic/random vibration, and estimate fatigue life of components or structures under repeated stress.
Thermal & Coupled Analysis
-
Thermal analysis: simulate heat transfer, temperature loads, heat power, thermal stresses — good for cases when temperature effects matter (e.g., design of components subject to thermal cycles).
-
Combined / multiphysics workflows: because ZWSim supports both structural and thermal loads/contact/constraints, it can handle more complex, realistic scenarios.
System Requirements:
- Windows 10/11
- CPU: Intel Core 2 Duo or AMD Athlon X2 CPU or higher (recommended)
- Disk Space: GB free space in OS disk, 2 GB free space in installation
- Memory: 2GB or more (recommended)
- GPU: 1GB or more (recommended)
- Resolution:1024 x 768VGA display with True Color (minimum), 1440×900 with NVidia 8 series or Radeon HD series or higher.
